Dunn 12 Inch Warm White Modular LED Under Cabinet Lighting - Hardwire Kit (6 Panel)
Quantity:
- Bright 1,800 Lumen (about 20 percent brighter than most under cabinet lighting available in the market).
- Each individual unit has Bright 49 LED
- Only Consumes 30 Watt Maximum. Saves at least 80 percent on energy.
- 24 Voltage (24VDC) offers highly energy-efficient, minimum heat contribution, longer lifespan, and safer.
- The light distributes in 180 Degree Beam Angle to optimize and maximize lighting under the cabinet.
- Easily Control the Brightness to the desired level using the inline dimmer switch.
- To ensure maximum safety, Modular LED Light Panel has been Certified by UL.
What's Included
- 6 x Dunn 12 Inch Warm White (3000K) Modular LED Under Cabinet Lighting Panel
- 1 x 50 Watt Dimmable Transformer - Link Up to (10) Dunn 12 inch LED Panel
- 1 x Wall Dimmer Switch w/ Wallplate (White)
- 1 x 6ft Interconnect Cable for Modular LED Under Cabinet Lighting (One End with Bare Wire)
- 6 x 3ft Interconnect Cable
- 6 x Modular Connector
- 12 x Mounting Bracket w/ Screw
[Dimension]
Dunn 12 Inch LED Light Panel
11.75 x 1.30 x 0.35 Inch. (300 x 33 x 9 mm)
Modular Connector
0.62 x 1.28 x 0.35 Inch (15.75 x 32.5 x 9 mm)
Electrical | |
Wattage | 30 Watt |
Voltage | 120 Volt |
Power Supply | 40 Watt |
Working Voltage Range | AC110-220 |
Photometrics | |
Lumens | 1800 |
Life Hours | 40,000 |
Color | Warm White |
Bulb Shape | LED Panel |
Dimmable | Dimmable |
Color Temperature | 3000 Kelvin |
Beam Angle | 180 Degree |
LED Chipset Array | 49 LED |
Dimming Control | Wall Dimmer |
Dimensions | |
Length | 11.75 inch. |
Certifications | |
Certification | UL Listed / CE / RoHS |
Materials | |
Lighting Type | 12" Panel |
Installation | |
Expandable | Yes |
Other Specifications | |
Number of Lighting | 6 |
Series | Dunn |
