50 Watt Dimmable Transformer (24VDC) for LED Under Cabinet Lighting
[50 Watt Dimmable Transformer (24VDC)]
Use 50 Watt Transformer (24VDC) to hard wire and dim your LED under cabinet lighting with a wide variety of compatible wall dimmer switches. The transformer is easy and safe to install with a low-profile plastic enclosure and is the perfect choice for LED under cabinet lighting.
Features
- Output constant voltage
- Easy and safe installation
- Auto-Reset Protection for short circuits & over-voltage
- ETL Listed
Compatible Lighting
Support Files:
Wall Dimmer Switch Compatibility List
Modular LED Under Cabinet Lighting Power Requirement Chart
Troubleshoot:
If there is no power from the output, please change the polarity of the installed interconnect cable as shown in the link below.
Diagram
Electrical | |
Output Voltage | 24VDC |
Max Output Power | 100W |
Env. Protection Rating | Dry and Damp Locations |
